Product Features
- Multiple connectivity options: Supports Wiegand, OSDP, and RS-485 communication protocols
- Web-based configuration: Multi-language web interface secured with a separate password for easy and safe configuration
Specifications
| Category | Specification |
| OSDP | 2 × RS-485 ports |
| RS-485 | Optional |
| Ethernet | 10 / 100 Mbps |
| Communication | TCP / IP |
| Inputs | 8 inputs (Door Sensor, Push Exit, Security Alarm, Additional Buttons) |
| Reader Support | 2 × OSDP readers 2 × Wiegand readers (with LED and buzzer control) |
| Outputs | 12 open collector outputs for LED control |
| Relay Outputs | 4 (NC, NO, COM) |
| LED Status Indicators | 4 × Relay control 2 × Door open 2 × Push Exit button 2 × Security alarm 2 × Additional buttons |
| Power Supply | +12 V DC, PoE IEEE 802.3af |
| Power Consumption | 5 W (standard), 1.5 W (standby) |
| Backup Power | CR3032 coin battery for continuous NTP synchronization |
| Operating System | Linux |
| Interface | Multi-language web interface |
| Identifiers Storage | 100,000 identifiers |
| ACS Integration | Wiegand, OSDP |
| Built-in Wiegand Input | 8, 26, 32, 34, 37, 40, 42, 56, 58, 64, 66, 128, 256 (raw) bits |
| Built-in OSDP Input | OSDP v2.2 |
| Number of Wiegand Inputs | 2 |
| Keypad Support | Yes Readable code lengths: 4, 6, 8 bits |
| Supported Connections | Door sensors (2 inputs) Exit buttons (2 inputs) Security alarm Fire alarm Additional buttons (2 inputs) |
| Authentication | Separate password for web interface |
| Additional Features | Link software support Open API Flexible configuration of connected devices |
